Specification:
Input voltage: VAC: 20-80V VDC: 24-110V
Maximum current: 8,4A peak (8 current options)
Microsteps: 400- 51200 (16 subdivisions)
Frequency: 200KHz
Dimentions: 150x98x52mm
Weight: 511g
DM860H is a type of two-phase hybrid stepping motor driver, The drive voltage of which is from 24VDC to 110VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 57mm to 110mm outside diameter and less than 8.0A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, and computer embroider machine, packing machines and so on.
