Specification:
Shank diameter 8 mm
Cutting surface diameter 8 mm
Length of cutting surface 16 mm
Overall length 60 mm
Hardness: HRC62
Protective coating: F-Nano
Description:
2 Flutes TiAlN F-NaNo Blue Coated Ultra Micro Grain Carbide for high hardened steels up to HRC62.
Two super sharp blades for standard cutting with high chip removal speed.
The F-Nano coating increases the stability of the cut and extends tool life during cutting.
Spiral design significantly improves cutting speed and creates a smooth and fine cutting surface.
Pre Hardened and Hardened Steel 40-50HRC - RPM 40000 Feed 320 mm/min
Hardened Steel 50-60HRC - RPM 40000 Feed 320 mm/min
High Hardened Steel 60-62HRC - RPM 32000 Feed 260 mm/min
Data sheet
Specifications: Shank diameter 6 mm Cutting diameter 6 mm Cutting length 12 mm Overall...
Specifications: Shank diameter 6 mm Cutting diameter 5 mm Cutting length 10 mm Overall length 50 mm
Specifications: Shank diameter 10 mm Cutting diameter 10 mm Cutting length 20 mm Overall...
Specifications: Shank diameter 8 mm Radius: 4mm Cutting length 25 mm Overall length 60 mm...
Specification:
Shank diameter 8 mm
Cutting surface diameter 8 mm
Length of cutting surface 16 mm
Overall length 60 mm
Hardness: HRC62
Protective coating: F-Nano
