24v Brushless Driver BLD-300B For 3 Phase Nema 23

This drive is suitable for power 48V 440W, 24V 300W three-phase sinusoidal brushless DC motor speed control, It can supply

external potentiometer speed control, external analog voltage control, PC (PLC, microcontrollers, etc.) PWM frequency control and

other functions . Meanwhile, the drive has high torque start, fast start-up and braking, reversing switch, manual and automatic

speed control combined with abnormal alarm signal output characteristics.

 Features

 *  can be applied to the host computer (PLC or microcontroller) PWM frequency or analog speed

 *  can be manual speed control mode (own potential, but also external potentiometer manual speed) PID speed loop, current loop

   control

 *  start stop control

 *  reversing control

 *  Overload Setting: Psv can set different parameters of the different power of the motor protection

 *  High-speed torque output stable, speed stable

 *  Hall angle of 60 ° / 300 ° 120 ° / 240 ° electrical angle selection

 *  pole set: 4-pole 8-pole optional fit different electrical specifications

 *  overcurrent, overvoltage, undervoltage, stall, Hall signals illegally, temperature protection

 *  Speed signal output

 *  Abnormal alarm signal output

 *  Undervoltage (≤18V), overheat (> 95 ℃) automatic protection

 *  With the brake function

 *  communication function, the controller speed, display speed, and other functions (sold separately)
