Specifications:
Input voltage: DC 24 ~ 50V
Maximum current: 5,6A (peak)
15 selectable microstep options
Pulse input frequency up to 200 KHz, TTL compatible and optically isolated input. Automatic idle-current reduction. Suitable for 2-phase. 15 selectable microstep resolutions.
Package Included: 1 x 5 axis CNC Breakout Board with optical coupler for Stepper Motor Driver...
Model: 57HS11242A4D8 Step angle: 1.8 degrees Number of phases: 2 Torque: 3 Nm Shaft diameter:...
Specifications: Input voltage: DC 18 ~ 50V Maximum current: 4.2A (peak) 15 selectable...
Input voltage 100-120V 6.8A, 60Hz or 200-240V 3.4A, 50Hz Output voltage 36V Output range of...
Specifications:
Input voltage: DC 24 ~ 50V
Maximum current: 5,6A (peak)
15 selectable microstep options
CNC milling machines
CNC Lasers
