Specification:
Dimension: 65x180mm (Diameter:65mm x Length:180mm)
Power:0.8 KW
Voltage: 220V~250V
Frequency: 400 Hz
Speed: 0-24000 R/min
Air Cooling
ER11 collet chuck(3.175mm, 6mm)
Runout off: less than 0.05mm
Grease Lubrication
High-quality air-cooled spindle made of stainless steel and high-quality bearings. Clamping ER11 possibility of clamping collets from 1-8 mm. Throw: less than 0.05 mm.
The spindle has the following advantages: stable performance, easy operation, high quality, low noise, etc.
Data sheet
Specifications: Model: ER11 A Material: 40CR steel Outside diameter: 19 mm Height: 12 mm...
Specification: Style: ER11 1-7 mm Set of 7 pieces : ( 1/,2,3,4,5,6,7mm) Material: High Grade...
Specification: Style: ER11 Material: High Grade 45 Carbon Steel Total height: 18 mm Outer...
Manufacturer: HELUKABEL Number of cores: 4 Core cross section: 0.75mm2 Core marking: colored...
Specification:
Dimension: 65x180mm (Diameter:65mm x Length:180mm)
Power:0.8 KW
Voltage: 220V~250V
Frequency: 400 Hz
Speed: 0-24000 R/min
Air Cooling
ER11 collet chuck(3.175mm, 6mm)
Runout off: less than 0.05mm
Grease Lubrication
