Nema17 stepper motor with encoder 0.48N.M closed loop
Specification:
Model: 42HS48EIS-P
Step angle: 1.8 degrees
Number of phases: 2
Current: 2A
Torque: 0.48 N.M.
Shaft diameter: 5 mm
Shaft length: 22mm
Dimensions: 42 x 42 x 70mm
Weight: 408g
Stepper motor is known by its property to convert a train of input pulses into a precisely defined increment in the shaft position.
This is a high quality motor that can be used for a long time without stuck.
It has a quite stable performance during work and will not loss step.
Low noise and big torque, this is a great choice if you need a stepper motor.
Stepper motor can be widely used for 3D printer, CNC engraving machine, etc.
Data sheet
- Current
- 2 A
- Step angle
- 1.8°
- Moment
- 0.48 NM
- Flange
- NEMA 17
- Shaft diameter
- 5mm
