Specification:
Model: 42HS4013A4XG
Step angle: 1.8 degrees
Number of phases: 2
Voltage: 3.8V
Current: 1.3A
Torque: 0.38 N.M.
Shaft diameter: 5 mm
Shaft length 6 mm
Cable length: 60cm
Dimensions: 42 x 42 x 40 mm
Stepper motor is known by its property to convert a train of input pulses into a precisely defined increment in the shaft position.
This is a high quality motor that can be used for a long time without stuck.
It has a quite stable performance during work and will not loss step.
Low noise and big torque, this is a great choice if you need a stepper motor.
Stepper motor can be widely used for 3D printer, CNC engraving machine, etc.
The motor is suitable for connection to a 42XG type planetary gearbox
