Specifications:
Shank diameter 4 mm
Cutting edge diameter 4 mm
Cutting edge length 10 mm
Overall length 50 mm
2 Flutes solid carbide mill cutter slot drill
Two flutes for standard cutting and high rate of chip removal
With TiAIN coated for increasing cutting stability, edge retention and up to three times longer cutting life
Spiral design, greatly improve the cutting speed, makes a smooth and delicate cutting surface
High precision super sharp, wear-resistant, durable
Used for semi-finishing operations, do slotting, profiling & plunging operations
Suitable for: Steel, Cast Iron and General Use on Materials up to 55HRC,
Cast Iron, Nodular Cast Iron - RPM 10800 Feed 560 mm/min
Carbon Steel, Alloy Steel -750N/Mm2 - RPM 10800 Feed 560 mm/min
Carbon Steel, Alloy Steel 40HRC - RPM 8000 Feed 425 mm/min
Pre Hardened Quenched and Tempered Steel 50HRC - RPM 6500 Feed 335 mm/min
Stainless Steel - RPM 5500 Feed 135 mm/min
