Two flutes carbide end mill cutter AlTiN coated 4/10 mm
Specifications:
Shank diameter 4 mm
Cutting edge diameter 4 mm
Cutting edge length 10mm
Overall length 50mm
2 Flutes solid carbide mill cutter slot drill
Two flutes for standard cutting and high rate of chip removal
With AITiN coated for increasing cutting stability, edge retention and up to three times longer cutting life
Spiral design, greatly improve the cutting speed, makes a smooth and delicate cutting surface
High precision super sharp, wear-resistant, durable
Used for semi-finishing operations, do slotting, profiling & plunging operations
Suitable for: Steel, Cast Iron and General Use on Materials up to 45HRC,
Cast Iron, Nodular Cast Iron - RPM 10800 Feed 465 mm/min
Carbon Steel, Alloy Steel -750N/Mm2 - RPM 10800 Feed 465 mm/min
Carbon Steel, Alloy Steel 30HRC - RPM 10000 Feed 430 mm/min
Pre Hardened Quenched and Tempered Steel 40HRC - RPM 8000 Feed 335 mm/min
Data sheet
- Cutting surface diameter
- 4mm
- Shank diameter
- 4mm
- Cutting surface length
- 10 mm
- Total length
- 50mm
- Hardness
- HRC 45
- Protective layer
- AlTiN
- Number of blades
- 2
- Tool type
- Front shank
- Tool material
- Carbide
